About this item

Three-in-One Rollers: Rolling mill rollers with three-in-one performance can press gold and silver into multiple sheet sizes, square wire, and semicircle. They are also easy to modify to meet your varying requirements.

Sturdy and Durable: This rolling mill machine is made of 55HRC steel rollers with a heat treatment process and has a high-quality cast iron hand crank and an A3 steel frame with spray paint, which is not easy to deform after long-term use.

Labor Saving Design: The reduction gear ratio of 2.4:1 allows the rollers to make one complete turn for every three turns of the rolling mill handle, and also the pinion drives the oversized gear, which can both relieve the amount of force needed to operate the rolling mill.

Safe to Use: The gear covers are made of high-quality A3 steel on both sides of the machine and are designed to protect you from hidden danger under standard operation.

High Stability: Screw holes are provided at the base of this manual rolling mill machine to fasten it to your workbench, allowing it to work steadily.

Adjustable Press Thickness: The distance between the rollers can be precisely adjusted within 0.7 inches through the T-shape gear handle to suit different usage scenarios.

Details

Gear Handle: The T-shaped handle connects to the parallel adjustment gears, allowing you to set the distance between rollers according to the textures and size of items.

Extra Long Hand Crank: The long crank with a cast iron body part and a slip-resistant ABS grip allows for even force application and effortless, smooth use.

Specification

Color: Green

Material: Cast Iron, 55HRC Steel, A3 Steel, ABS

Treatment: Spray Paint, Heat Treatment Process

Assembly Required: Yes

Gear Ratio: 2.4:1

Thickest Compressibility: 18mm/0.7inch

Thinnest Compressibility: 0.01mm/0.0004inch

Upper Roller Length: 9cm/3.54inch

Middle Roller Length: 5cm/1.96inch

Square Grooves Width: 4cm/1.57inch

Semicircle Grooves Width: 4.5cm/1.77inch

Roller Total Length: 12cm/4.7inch

Roller Diameter: 5cm/1.96inch

Space of Two Rollers: 0-25mm/0-0.7inch

Square Wire: 1/2/2.5/3/3.5/4/5mm

Semicircle Wire: 2/3/4/5/6/9mm

Maximum Sheet Width: 45mm/1.8inch

Hand Crank Length: 29cm/11.4inch
